HEF4023BP
Manufacturer:
Nxp Semiconductors
Mfr.Part #:
HEF4023BP
Datasheet:
Description:
Logic Gates, Inverters DIP-14 Through Hole NAND HEF4000 Low Level Output Current:-3.6 mA High Level Output Current:3.6 mA
| Parameter | Value |
|---|---|
| Length | 19.5 mm |
| Width | 6.48 mm |
| Termination | Through Hole |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 14 |
| Height | 3.2 mm |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Number of Elements | 3 |
| Output Current | 2.4 mA |
| Operating Supply Voltage | 15 V |
| Output Type | Voltage |
| Max Supply Voltage | 15 V |
| Min Supply Voltage | 3 V |
| Propagation Delay | 135 ns |
| Logic Function | NAND |
| Number of Inputs | 3 |
| Number of Gates | 3 |
| Schmitt Trigger Input | No |
| Low Level Output Current | -3.6 mA |
| High Level Output Current | 3.6 mA |
| Number of Circuits | 3 |
| Number of Outputs | 1 |
| Packaging | Bulk |
| Logic Family | HEF4000 |
